Parallel is built for the independent cyclist who refuses to compromise. This aluminum racing frame delivers the performance you demand with the reliability you can trust and maintain yourself. Parallel gives you true ownership: a bike you can repair, upgrade, and rely on for years
Designed and engineered in The Netherlands, carefully crafted in Taiwan from double and triple butted AL7005 tubes.
BUILD FOR CONFIDENCE
Whether you search for full confidence on the road and every corner you take, or for the confidence to maintain your bike. This will be the one that gives you the confidence to do it all.
Details
- Model Parallel Gen II
- Engineered in The Netherlands
Frameset
- Material Made of 7005 series Aluminium. Tubes are double butted. Frame is smooth welded and after welding had a T4 and T6 Heat treatment and got shot peened.
- Fork Columbus Futura Disc Integrated. Full carbon fibre. 1,5 to 1,125 inch tapered steered. Flat mount brakes, made for 140 or 160mm rotors. Internal cable routing.
- Headtube Made for Integrated headsets, IS52 bearing size. This results in the option to integrate cable's and brake hoses through the headtube and upper bearing.
- Bottom bracket T47 threaded bottom bracket. 86,5mm wide, made for internal bearings. BB's made for 85,5 or 86mm also fit. (Yes, these are different 'standards')
- Tyre clearance Designed for 28mm, but easily fits 25 to 30mm. Other sizes might fit, depending on rim and tyre combination.
- Wheel size 28 inch or 700c.
- Front axle (disc) 12x100mm thru-axle. Axle is 120mm long with M12x1.5 thread.
- Rear axle (disc) 12x142mm thru-axle. Axle is 162mm long with M12x1.5 thread.
- Stem Raamwerk aluminium stem in matching color. Made for optional out-front mount, to mount your Garmin, Wahoo, Karoo, Action Camera, front light, and/or bell.
- Seat post Fully integrated. With 34.9mm seat mast (included). Up to 40mm of adjustabillity in height. Removing the Integrated Seat Post is also possible, in that case you can mount a 27.2mm seat post.
- Available Sizes XS, S, M, M/L, L, XL
WITH EVERY CORNER
Uphill, in a criterium or full send down-hill , the race geometry, intuitive handling and the exquisite frame characteristics will make you feel comfortable with pushing the limits.
| Framesize | XS | S | M | M/L | L | XL | |
|---|---|---|---|---|---|---|---|
| Body length (roughly | 160 | 168 | 175 | 180 | 185 | 192+ | |
| A | Stack | 494 | 509 | 525 | 544 | 565 | 589 |
| B | Reach | 375 | 378 | 388 | 398 | 403 | 404 |
| C | Seat tube angle | 75 | 74 | 73,5 | 73,5 | 73 | 72,5 |
| D | Seat tube C-C | 450 | 490 | 510 | 530 | 550 | 580 |
| E | Seat tube C-T* | 750 | 790 | 810 | 830 | 850 | 880 |
| F | Top tube (effective) | 505 | 525 | 545 | 560 | 575 | 590 |
| G | Head tube angle | 71 | 72,5 | 73 | 73 | 73,5 | 73,5 |
| H | Head tube | 110 | 120 | 135 | 155 | 175 | 200 |
| I | Bottom bracket drop | 68 | 68 | 68 | 68 | 68 | 68 |
| J | Wheel base | 972 | 966 | 978 | 993 | 999 | 1008 |
| K | Stand-over height | 741 | 777 | 795 | 815 | 832 | 860 |
| L | Fork offset | 45 | 45 | 45 | 45 | 45 | 45 |
| M | Fork Length | 375 | 375 | 375 | 375 | 375 | 375 |
| N | Trail | 70 | 61 | 58 | 58 | 55 | 54 |
| * With ISP included |
Technical documentation
All the details
As we celebrate to build and maintain your bike yourself. We give you access to all details that you'd need to build the frameset to bike.
Customer support
Our dedicated team provides timely assistance, committed to addressing your queries.
Guaranteed satisfaction
Invest in our frameset with absolute confidence, backed by our 30-day satisfaction guarantee.
Crash replacement
Unfortunately crashes happen, and if they do we will help you to get back on your bike a.s.a.p.
